3mp IP Network PTZ Weatherproof with IR & 20x Zoom
Sibell IPPTZ-SB3IR20X IP Network PTZ Weatherproof for video security provides 3 Mega Pixel real-time resolutions at 30fps. This powerful Pan Tilt and Zoom camera Supports select area amplification and PTZ functions, Sensitive smart alarm triggers and motion detection and Two-way audio for additional audio security. This Powerful PTZ camera also supports the Sibell Starlight feature set, providing exceptional video images at night and provides Night Vision IR distance up to 325 Feet. the IPPTZ-SB3IR20x is IP66 Rated weatherproof with TVS 6KV lightning/ surge protection protecting this camera from all types of weather conditions. All Sibell IP cameras have ONVIF allowing for integration with other ONVIF devices.
Key Features:
- 3 Mega Pixel ( 2048 x 1536 @25/30fps)
- H.265 Video Encoding (optional)
- SD card local storage
- Supports select area amplification and PTZ functions
- Smart Alarm Motion & Sensor
- 325 feet IR night view distance & Starlight Feature set
- Supports local CVBS video output and two-way audio
- IP66 Weatherproof
- TVS 6KV lightning protection, surge protection
- 24vAC Power Supply
- Supports smart phone, iPad, remote monitoring
Description
Model#: IPPTZ-SB3IR20X IP Network PTZ Weatherproof with IR & 20x Zoom |
|
| Camera | |
| Image Sensor | 1 / 3 “ Progressive CMOS |
| Image Size | 2048 x 1536 3MP (1200 TVL) |
| Electronic Shutter | 1 / 25 s ~ 1 / 100000 s |
| Min. Illumination | 0 LUX |
| IR Distance | 325 feet (100m) |
| White Balance | Auto/ Manual |
| S/N Ratio | Max 48dB |
| Day/ Light | Auto/ Manual |
| Focus Mode | Auto/ Manual |
| Lens | 20x Zoom, f=5.5~110 mm, F1.6 ~ F3.5 |
| PTZ | |
| Pan Range | 360° endless rotation |
| Pan Speed | Preset speed : 240 °/s; Manual control speed : 0.5 ~ 90 °/s |
| Tilt Range | 0 ~ 93° ( auto rotation ) |
| Tilt Speed | Preset speed : 160 °/s; Manual control speed : 0.5 ~ 90 °/s |
| System | |
| PTZ Control | Yes |
| Preset | 255 |
| Cruise | 8 |
| Track | 4 |
| Time Task | 8 |
| Scan | 2 |
| Home Position | Yes |
| Auto Flip | Yes |
| OSD Menu | English |
| Alarm | Input: 1 Output: 1 |
| Alarm Linkage | Yes |
| Network | |
| Compression | H.265 |
| Frame Rate | 1 ~ 30fps ( 25 fps ) |
| Protocol | TCP / IP, UDP, DHCP, DDNS, NTP, RTSP, SMTP, FTP, PPPoE |
| Storage | SD card local storage, network remote storage |
| Smart Alarm | Motion Alarm, Sensor Alarm |
| Resolution | 3MP (2048 × 1536 ), 1030%P ( 1920 × 1030% ), 720P ( 1230% × 720 ), VGA ( 640 × 430% ) |
| Multi-stream | yes |
| Port | |
| Network Interface | 10 Base-T / 100 Base-TX, RJ45 |
| Audio | MIC input × 1, MIC output × 1 |
| Other | |
| Control | Network |
| Power Supply | AC 24V / 3000 mA |
| Power Consumption | 15 W ( max 30W, IR on ) |
| Working Environment | Temperature : – 20 °C ~ 60 °C; Humidity : less than 95% |
| Protection Level | IP66; TVS 6KV lightning protection, surge protection |
| Weight | 3.5KG |
| Dimensions ( mm ) | ø 209 × 317 |
Documents
Download “IPPTZ-SB3IR20X Specsheet”
IPPTZ-SB3IR20X-Specsheet.pdf – Downloaded 702 times – 257.79 KBDownload “IPPTZ-SB3IR20X Quick Start Guide”
IPPTZ-SB3IR20X-QSG.pdf – Downloaded 993 times – 1.82 MBDownload “Sibell PTZ User Manual”
