PTZ Keyboard Controller

PTZ-SBKEYBOARD PTZ Keyboard Controller for use with High Speed Dome Cameras and pan tilz and zoom cameras (PTZs). This has a 3 axis joystick control for PTZ functions and Remote Control Pan/Tilt/Zoom of Dome PTZ Camera, can control pan/ tilt, rotation, iris, preset tour, pattern, Zoom-In, Zoom-Out and Focus Directly. Connect easily using the RS485 control bus, control 255 front-end addresses and connect up to 128 devices in parallel. Standard RS485 I/O ports are all lightning proof and protect against interference. Standard communication distance is up to 1200m or 3937 feet.

SKU: PTZ-SBKEYBOARD. Categories: , .

Product Description

Model#: PTZ-SBKEYBOARD PTZ Keyboard Controller
Keyboard Controller
ItemParameters
Power SupplyDC12V ± 10%/50HZ
Temperature-10~55 °C
Humidity<90%RH (No cream node)
ComminicationRS485 Half-duplex
Baud Rate1200bps, 2400bps, 4800bps, 9600bps, 19200bps
Interface5PIN Pressure Line Terminal
Direction NotificationOn LCD screen
Exterior Size305 (L) x 148 (W) x 82 (H) mm
