8ch Sibell Compact NVR 1HDD with PoE

NVR-SB8ME-8P 8ch Sibell Compact NVR 1HDD with PoE  supports camera resolutions from 720p to 5 Mega Pixels. H.265 High profile compression available to help save you on hard drive space. This 8ch Sibell NVR 1HDD with POE can take a single hard drive up to 6TB. The Sibell User interface was designed for usability, and can easily be interpreted as one of the most intuitive systems developed and embedded. This 8 channel machine has POE to power compatible cameras and will also take ONVIF compatible devices.

Key Features:

  • Support 8ch 1MP(720p) – 5MP Inputs
  • H.265 high profile compression format
  • Intuitive, user-friendly GUI with Modular Design
  • Recording Modes in Manual, motion, sensor or timer
  • Search video: by time, event, time slice, and tag search
  • Express backup options
  • Remote Monitoring via Browser or CMS
  • Mobile Viewing Via Sibell Mobile App on IOS & Android
  • NAT function & QRCode scan to set up mobile viewing
  • 8 PoE ports for Direct Camera Connection & Power
  • Dual Stream Technology

Click Here to Learn More about the User Interface Features

Description

Model#: NVR-SB8ME-8P 8ch Sibell Compact NVR 1HDD with PoE

System Compression Standard H.265
OS Embedded Linux
Video Network Input 8 CH IPC input
Bandwidth 64Mbps
Network Access Format



5MP / 4MP / 3MP / 1080P / 960P / [email protected] / 30fps



Output HDMI × 1: 4K x 2K/ 1920 x1080/1280 x1024

VGA x1: 1920×1080/ 1280 x 1024

Audio Network Input 8 CH IPC audio input
2-way Audio RCA x 1
Local Output RCA x 1
Record Record Stream Dual stream recording
Resolution 5MP / 4MP / 3MP / 1080P / 960P / 720P
Mode Manual, timer, motion, sensor
Playback Simultaneous Playback Max 8 CH
Search Time slice / time / event / tag search
Smart Search Highlighted color to display the camera record in a certain period of time, different colors refers to different record events



Function Play, pause, FF, FB, digital zoom, etc.
Alarm Mode Manual, sensor, motion, exception
Input Support IPC alarm input
Output Support IPC alarm output
Triggering Record, Snap, Preset, e-mail, ect
Network Interface RJ45 10 / 100 Mbps  × 1
PoE Port RJ45 × 8
Protocol TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP
Web Client Max 10 users online
Mobile Device OS IOS, Android
Storage HDD SATA x1, 6TB Max per Hard Drive
Backup Local Backup U disk, USB mobile HDD
Network Backup Yes
Port USB USB 2.0 × 2 ( one in the front panel and the other in the rear panel )
Remote Controller Yes
Others Power Supply DC48V
Consumption ≤ 5W ( without HDD )
Dimensions 12 × 11 × 2.2 ( W × D × H ) in
Environment -10 °C ~ 50 °C 10% ~ 90% humidity

Documents

Download “NVR-SB8ME-8P Specsheet” NVR-SB8ME-8P-Specsheet.pdf – Downloaded 324 times – 254 KB

Download “NVR-SB8ME-8P Quick Start Guide” NVR-SB8ME-8P-QSG.pdf – Downloaded 320 times – 1 MB

Download “Sibell NVR Manual” Sibell-2016-NVR-manual.pdf – Downloaded 2337 times – 6 MB
