8ch Sibell Compact NVR 1HDD

NVR-SB8ME 8ch Sibell Compact NVR 1HDD supports camera resolutions from 720p to 5 Mega Pixels. This 8ch Sibell unit has H.265 High profile compression available to help save users on hard drive space. The 8ch Sibell NVR 1HDD comes with single hard drive bay and can accept up to a 6TB drive. The Sibell User interface was designed for usability, and can easily be interpreted as one of the most intuitive systems developed and embedded. This 8 channel machine is ONVIF compatible and works with ONVIF devices.

Key Features:

  • Support 8ch 1MP(720p) – 5MP Inputs
  • H.265 high profile compression format
  • Intuitive, user-friendly GUI with Modular Design
  • Recording Modes in Manual, motion, sensor or timer
  • Search video: by time, event, time slice, and tag search
  • Express backup options
  • Remote Monitoring via Browser or CMS
  • Mobile Viewing Via Sibell Mobile App on IOS & Android
  • NAT function & QRCode scan to set up mobile viewing
  • Dual Stream Technology

Click Here to Learn More about the User Interface Features

Product Description

Model#: NVR-SB8ME 8ch Sibell Compact NVR 1HDD

SystemCompressionStandard H.265
OSEmbedded Linux
VideoNetwork Input8 CH IPC input
Bandwidth64Mbps
Network Access Format



5MP / 4MP / 3MP / 1080P / 960P / [email protected] / 30fps



OutputHDMI × 1: 4K x 2K/ 1920 x1080/1280 x1024
AudioNetwork Input8 CH IPC audio input
2-way AudioRCA x 1
Local OutputRCA x 1
RecordRecord StreamDual stream recording
Resolution5MP / 4MP / 3MP / 1080P / 960P / 720P
ModeManual, timer, motion, sensor
PlaybackSimultaneous PlaybackMax 8 CH
SearchTime slice / time / event / tag search
Smart SearchHighlighted color to display the camera record in a certain period of time, different colors refers to different record events



FunctionPlay, pause, FF, FB, digital zoom, etc.
AlarmModeManual, sensor, motion, exception
InputSupport IPC alarm input
OutputSupport IPC alarm output
TriggeringRecord, Snap, Preset, e-mail, ect
NetworkInterfaceRJ45 10 / 100 Mbps  × 1
PoE Portn/a
ProtocolTCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP
Web ClientMax 10 users online
Mobile DeviceOSIOS, Android
StorageHDDSATA x1, 6TB Max per Hard Drive
BackupLocal BackupU disk, USB mobile HDD
Network BackupYes
PortUSBUSB 2.0 × 2 ( one in the front panel and the other in the rear panel )
Remote ControllerNo
OthersPower SupplyDC48V
Consumption≤ 5W ( without HDD )
Dimensions12 × 11 × 2.2 ( W × D × H ) in
Environment-10 °C ~ 50 °C 10% ~ 90% humidity

Documents

Download “NVR-SB8ME Specsheet” NVR-SB8ME.pdf – Downloaded 44 times – 241 KB

Download “Sibell NVR Manual” Sibell-2016-NVR-manual.pdf – Downloaded 321 times – 6 MB
