32ch Sibell Tribrid DVR 8HDD TVI/AHD/Analog

QDVR-SBE32 32ch Sibell Tribrid DVR 8HDD TVI/AHD/Analog is a tribrid machine that supports up to 32 channels TVI, up to 32 channels AHD 2.0, up to 32 channels Analog. You can mix and match any 32 channel camera combination on this machine in TVI/AHD or Analog, Note: This device is not compatible with IP cameras. This is the ideal device for analog customer upgrades. The Sibell User interface was designed for usability, and can easily be interpreted as one of the most intuitive systems developed and embedded. This 32 channel Tribridbrid machine intuitive and affordable making for a pleasant user experience. Sibell Quadbrid machines accept ONVIF devices.

Key Features:

  • 32ch TVI / AHD 2.0 video input
  • 32ch 1080P / 1080P lite / 720P recording
  • H.264 high profile compression format
  • Intuitive, user-friendly GUI with Modular Design
  • Recording Modes in Manual, motion, sensor or timer
  • Search video: Time Slice, Time, Event or Tag Search
  • Express backup options
  • Remote Monitoring via Browser or CMS
  • Mobile Viewing Via Sibell Mobile App on IOS & Android
  • NAT function & QRCode scan to set up mobile viewing

Click Here to Learn More about the User Interface Features

Product Description

Model#: QDVR-SBE32 32ch Sibell Tribrid DVR 8HDD TVI/AHD/Analog

SystemCompressionStandard H.264
OSEmbedded Linux
VideoInputBNC x 32
IP Inputnone
Resolution



TVI / AHD 2.0 1080P, 720P, WD1 real time
OutputHDMI x 1:1920 x 1080, VGA x 1: 920 x 1080
AudioInputRCA x 16
OutputRCA x 1
2-way audioRCA x 1
RecordResolution1080P: 1920 x 1080, 720P: 1280 x 720, WD1
Frame Rate1080P : 400fps ( PAL) / 480fps (NTSC )
720P : 800 fps (PAL) / 960fps (NTSC)
Bit Rate768Kbps ~ 8Mbps
EncodeVBR / CBR
Quality6 Level
ModeManual, timer, motion, sensor
File ManagerLock, unlock
PlaybackPlayback8 CH
SearchTime / calendar search, event ( motion, external alarm )
Smart

Search

Highlighted date and time to display the channel record
FunctionPlay, Pause, FF, FB, Digital zoom
AlarmModeSensor, motion, video loss
Input16CH
Output4 CH
TriggeringRecord, PTZ move, alarm out, e-mail, etc
NetworkInterfaceRJ45 10M / 100M x 1
ProtocolTCP / IP, UDP, DHCP, DNS, PPPOE, DDNS
Web Client10 users online, dual stream
Mobile DeviceOSIOS, Android
StorageHDDSATA x 8, e-SATA x 1
OthersPower SupplyDC 12V
Consumption≤ 26W ( without HDD )
Dimensions430 × 450 × 90 ( W × D × H )
Environment-10 °C ~ 50 °C 10% ~ 90% humidity

Documents

Download “QDVR-SBE32 Specsheet” QDVR-SBE32-Specsheet.pdf – Downloaded 253 times – 622 KB

Download “QDVR-SBE32 Quickstart Guide” qdvr-sbe32-quick-start-guide.pdf – Downloaded 223 times – 2 MB

Download “Sibell Quad Machine DVR Manual” Sibell-Quad-MachineDVR-user-manual.pdf – Downloaded 449 times – 6 MB
